Description
PRODUCT NUMBER
MLX-D24M-A18PW-R1
EXTERIOR COLOUR
White
CPU SOCKET
LGA2066, LGA2011-v3, LGA2011, LGA1700*, LGA1200, LGA1151, LGA1150, LGA1155, LGA1156, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1
RADIATOR MATERIAL
Aluminium
RADIATOR DIMENSIONS
277 x 119.6 x 27.2 mm
PUMP DIMENSIONS
81.4 x 76 x 57.8 mm
PUMP MTTF
70,000 Hours
PUMP NOISE LEVEL
< 10 dBA
PUMP CONNECTOR
3-Pin
PUMP RATED VOLTAGE
12 VDC
PUMP POWER CONSUMPTION
2.36 W
FAN DIMENSIONS (L X W X H)
120 x 120 x 25 mm
FAN QUANTITY
2 PCS
FAN LED TYPE
Addressable Gen 2 RGB
FAN SPEED
650-1800 RPM ± 10%
FAN AIRFLOW
47.2 (Max)
FAN NOISE LEVEL
6 - 30 dBA
FAN PRESSURE
1.60 mmH₂O (Max)
FAN LIFE EXPECTANCY
160,000 Hours
FAN POWER CONNECTOR
4-Pin (PWM)
FAN RATED VOLTAGE
12VDC
FAN RATED CURRENT
0.25A
RAM CLEARANCE
N/A
WARRANTY
3 Years
SERIES
MasterLiquid
COOLER TYPE
Liquid Cooler
RADIATOR SIZE
240mm
