Description
CX550 CABLE LISTING
| QTY | Cable | Connectors per cable |
Total connectors |
Connector Spacing |
Total length |
|---|---|---|---|---|---|
| 1 |
ATX Cable (24-PIN) (24)
|
1 | 1 | - | 600mm ± 10mm |
| 1 |
EPS/ATX12V Cable (8-PIN) (4+4)
|
1 | 1 | - | 600mm ± 10mm |
| 1 |
PCI-E Cable (8-PIN) (6+2)/(6+2)P
|
2 | 2 | 500mm, 100mm | 600mm ± 10mm |
| 1 |
SATA CABLE (3 SATA)
|
3 | 3 | 400mm, 100mm, 100mm | 600mm ± 10mm |
| 1 |
PATA CABLE (2PATA)
|
2 | 2 | 400mm, 100mm | 500mm ± 10mm |
Specifications
ATX Connector
1
ATX12V Version
2.4
Continuous Power W
550 Watts
EPS Connector
1
SATA Connector
3
PATA Connector
2
Dimensions
125 x 150 x 86
Modular
No
PCIe Connector
2
80 PLUS Efficiency
Bronze
Weight
1.87 Kg
Package Contents
• CX550 Power Supply
• Power Cord
• Mounting Screws
• Cable Ties
