Description
| Model | BR850ELCD |
| Capacity (VA/Watts) | 850VA / 510W |
| Energy-Saving Technology | Yes |
| Input | |
| Voltage Range | 160Vac - 265Vac |
| Frequency Range | 47Hz ~ 63 Hz (Auto Sensing) |
| Output | |
| UPS Output(numbers) | (8) AU Outlets(4 for battery backup & surge, 4 for surges) |
| On Battery Output Voltage | Simulated Sine Wave at 230Vac +/- 10% |
| On Battery Output Frequency | 50Hz / 60 Hz +/- 1% |
| Transfer Time (Typical) | 4ms |
| Overload Protection | On Utility: Circuit Breaker & Internal Current Limiting / On Battery: Internal Current Limiting |
| AVR | Yes |
| Surge Protection and Filtering | |
| Surge Protection | Yes |
| DSL/Phone/Fax/Modem protection | RJ11/RJ45(One In/One Out) |
| Physical | |
| Maximum Dimensions(H x W x D)(mm) | 113.6 x 271 x 160.7 |
| Weight(kg) | 6.4 |
| Battery | |
| Sealed Maintenance Free Lead Acid Battery |
12V 8.5AH x 1 |
| User Replaceable | Yes |
| Typical Recharge Time | 8 Hours |
| Runtimes | |
| Half-load/Full-load (mins) | 8/1 |
| Status Indication | |
| Indicators | Power On |
| Audible Alarms | On Battery, Low Battery, Overload |
| Communication | |
| Power Management Software | PowerPanel® Personal Edition |
| Management | |
| Self-Test | Yes |
