Description
Input Frequency Detection
Auto-sensing |
Rated Input Current ( A )
3.69 |
Input Connector Type
Schuko |
Power Cord Length (ft.)
4 |
Power Cord Length (m.)
1.2 |
OUTPUT
Capacity (VA)
850 |
Capacity (Watts)
425 |
On Battery Waveform
Simulated Sine Wave |
On Battery Voltage(s) ( Vac )
230 ± 10% |
On Battery Frequency ( Hz )
50 ± 1% |
60 ± 1% |
Automatic Voltage Regulation (AVR)
Single Boost, Single Buck |
Overload Protection
Internal Current Limiting, Fuse |
Outlet(s) - Total
3 |
Outlet Type
Schuko x 3 |
Outlet(s) - Battery & Surge Protected
3 |
Typical Transfer Time ( ms )
4 |
BATTERY
Runtime at 60W ( min )
30 |
Runtime at 90W ( min )
20 |
Runtime at 200W ( min )
6 |
Typical Recharge Time ( Hours )
6 |
Start On Battery
Yes |
User-replaceable
No |
Battery Type
Sealed Lead-acid |
SURGE PROTECTION & FILTERING
Surge Suppression ( Joules )
125 |
EMI/RFI Filtration
Yes |
Phone/Network Protection RJ11/RJ45 (Combo)
1-in, 1-out |
MANAGEMENT & COMMUNICATIONS
LED Indicators
Power On, Line Mode, Battery Mode, Bypass Mode, Low Battery, Overload, UPS Fault |
HID Compliant USB Port(s)
1 |
Audible Alarms
Battery Mode, Low Battery, Overload, UPS Fault |
Ethernet Data Transmission Speed
Up to 1Gbps |
Power Management Software
PowerPanel Personal (Recommended) |
PHYSICAL
Enclosure Construction
Plastic |
Color
Black |
PHYSICAL SIZE - UPS MODULE
Dimensions (WxHxD) (in.)
3.31 x 6.85 x 11.02 |
Dimensions (WxHxD) (mm.)
84 x 174 x 280 |
Weight (lbs.)
9.26 |
Weight (kg.)
4.2 |
SHIPPING DIMENSIONS
Dimensions (WxHxD) (in.)
4.29 x 9.02 x 12.4 |
Dimensions (WxHxD) (mm.)
109 x 229 x 315 |
Weight (lbs.)
9.86 |
Weight (kg.)
4.47 |
ENVIRONMENTAL
Operating Temperature (°F)
32 ~ 104 |
Operating Temperature (°C)
0 ~ 40 |
Operating Relative Humidity (Non-condensing) ( % )
0 ~ 90 |
Operating Elevation ( feet/meters )
0-9,843 feet (0-3,000 meters) |
Storage Temperature (°F)
-4 ~ 122 |
Storage Temperature (°C)
-20 ~ 50 |
Storage Relative Humidity (Non-condensing) ( % )
0 ~ 90 |
Storage Elevation ( feet/meters )
0-9,843 feet (0-3,000 meters) |
Online Thermal Dissipation ( BTU/hr )
34 |
CERTIFICATIONS
Certifications
CE |
RoHS
Yes |
WARRANTY
Product Warranty Period (Year)
2 |
Battery Warranty Period (Year)
2 |
