Description
-
-
Total Cores
10
# of Performance-cores
6
# of Efficient-cores
4
Total Threads
16
Max Turbo Frequency
4.90 GHz
Performance-core Max Turbo Frequency
4.90 GHz
Efficient-core Max Turbo Frequency
3.60 GHz
Performance-core Base Frequency
3.70 GHz
Efficient-core Base Frequency
2.80 GHz
Cache
20 MB Intel® Smart Cache
Total L2 Cache
9.5 MB
Processor Base Power
125 W
Maximum Turbo Power
150 W
Memory Specifications
Max Memory Size (dependent on memory type)
128 GB
Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/sMax # of Memory Channels
2
Max Memory Bandwidth
76.8 GB/s
Processor Graphics
Processor Graphics*
Intel® UHD Graphics 770
Graphics Base Frequency
300 MHz
Graphics Max Dynamic Frequency
1.45 GHz
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units
32
Max Resolution (HDMI)*
4096 x 2160 @ 60Hz
Max Resolution (DP)*
7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)*
5120 x 3200 @ 120Hz
DirectX Support
12
OpenGL Support
4.5
Multi-Format Codec Engines
2
Intel® Quick Sync Video
Yes
Intel® Clear Video HD Technology
Yes
# of Displays Supported*
4
Device ID
0x4680
OpenCL Support
2.1
Expansion Options
Direct Media Interface (DMI) Revision
4.0
Max # of DMI Lanes
8
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations*
Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes
20
-
