BD-ROM
BD-Video
Yes
BD-RE/ BD-RE DL (Ver.3)
BDAV/ BDMV/ JPEG/ MPO/ FLAC/ WAV/ AAC/ WMA/ MP3/ ALAC/ DSD
Yes*2
BD-R/ BD-R DL (Ver.2)
BDAV/ BDMV/ Xvid/ MKV/ FLAC/ WAV/ AAC/ WMA/ MP3/ ALAC/ DSD
Yes
DVD
DVD-Video
Yes
DVD-R*1/ DVD-R DL*1/ DVD-RW*1
DVD-Video/ DVD Video Recording
Yes*1
AVCHD
Yes*1
Xvid/ MKV/ FLAC/ WAV/ WMA/ AAC/ MP3/ ALAC/ DSD/ JPEG/ MPO
Yes (DVD-R/ DVD-R DL)*2
+R*1/ +R DL*1/ +RW*1
Video/ AVCHD
Yes
CD, CD-R/ -RW
CD-DA
Yes
Xvid/ MKV/ FLAC/ WAV/ WMA/ AAC/ MP3/ ALAC/ JPEG/ MPO
Yes (CD-R/ -RW)*2
AUDIO SYSTEM
Dolby Digital/ TrueHD
Yes Decode (2ch) and Bitstream Output
Dolby Digital Plus
Yes Decode (2ch) and Bitstream Output
DTS-HD Master Audio / DTS-HD High Resolution Audio
Yes Decode and Bitstream Output
FLAC
Yes (192kHz/24bit (5.1ch))
WAV
Yes (192kHz/32bit (2ch))
ALAC
Yes (192kHz/24bit (2ch))
DSD (DFF,DSF)
Yes (2.8MHz(2ch/ 5.1ch), 5.6MHz(2ch only))
USB
Slot
Yes
Front
For Playback
USB Standard
USB 2.0 High Speed
Xvid/ MKV/ MP4/ MPEG-2/ FLAC/ WAV/ WMA/ AAC/ MP3/ ALAC/ DSD/ JPEG/ MPO
Yes*2
HIGH QUALITY PICTURE
Deep Colour
Yes
x.v.Colour
Yes*5
EASY OPERATION
Quick Start Mode
Yes
HDMI-CEC
Yes
Stylish GUI/ Wallpaper
Yes/ yes
SMART NETWORKING
Internet Apps
Yes (Simple)*7
External HDD Playback
Yes*8
BD-Live™
YesTM9
TERMINAL
HDMI Output
Yes
LAN (Ethernet) Terminal
Yes (for BD-LiveTM*9, Internet Apps(Simple)*7 and Firmware Update)
OTHERS
Video System
PAL/ NTSC
HDMI Cable Included
Yes
Remote Control Included
Yes
Power Consumption
Power Supply
AC 220-240V, 50Hz
Normal Use
11W
Standby(Quick Start Off)
0.5W
Standby(Quick Start On)
3.5W
DIMENSIONS, WEIGHT
Dimensions (W x H x D)
245 x 38.5 x 175 mm
Weight
0.8 kg
Remarks
NOTE
*1 Discs recorded and finalized on recording devices.
*2 Except MPO.
*3 To enjoy 4K Upscaling playback you will also need a 4K/UHD TV.
*4 Only BD-Video 24p content can be up-converted for 4K2K resolution.
*5 This function is effective only when reproducing AVCHD data recorded with x.v.Colour technology.
The function cannot be used with BD-ROM or DVD-ROM discs. HDMI connection is required.
*6 Compatible with AndroidTM devices, Ver. 4.2 and above and Miracast certified.
For information on whether the smartphone, etc. supports Miracast, contact the manufacturer of the device.
*7 Requires broadband Internet service.
*8 The external HDD with capacities of 4TB or less in processing NTFS/ FAT32 data is supported.
Playback is not possible with some external hard disk drives.
*9 To enjoy content, you will need to insert a USB flash drive (1GB or more of free space/ sold separately). Requires broadband Internet service.
*10 Excluding the projecting parts and the pedestal.
Specifications are subject to change without notice. All numbers given here are approximate.
Please note this Blu-Ray Player is designed to play Region B Blu-Rays only.
