General Feature
Application
Client PCs
Rated Capacity
500GB (1GB=1 Billion byte by IDEMA)
* Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor
M.2 (2280)
Interface
PCIe Gen 3.0 x4, NVMe 1.4
Dimension (WxHxD)
80.15 x 22.15 x 2.38 (mm)
Weight
Max 8.0 g Weight
Storage Memory
Samsung V-NAND 3-bit MLC
Controller
Samsung Pablo Controller
Cache Memory
HMB (Host Memory Buffer)
Special Feature
TRIM Support
Supported
S.M.A.R.T Support
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
Encryption Support
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support
Not supported
Device Sleep Mode Support
Yes
Performance
Sequential Read
Up to 3,100 MB/s *
Sequential Write
Up to 2,600 MB/s *
Random Read (4KB, QD32)
Up to 400,000 IOPS *
Random Write (4KB, QD32)
Up to 470,000 IOPS *
Random Read (4KB, QD1)
Up to 17,000 IOPS *
Random Write (4KB, QD1)
Up to 54,000 IOPS *
* Performance may vary based on system hardware & configuration
Environment
Power Consumption
Average: 4.63 W* Maximum: 5.9 W (Burst mode)*
Power Consumption (Idle)
Max. 45 mW *
Allowable Voltage
3.3 V ± 5 % Allowable voltage
Reliability (MTBF)
1.5 Million Hours Reliability (MTBF)
Operating Temperature
0 - 70°C Operating Temperature
Shock
1,500 G & 0.5 ms (Half sine)
* Actual power consumption may vary depending on system hardware & configuration
Accessories
Installation Kit
Not Available
Software
Management SW
Magician Software for SSD management
Warranty
5-Year Limited Warranty or 300 TBW Limited Warranty
