Description
Specifications
* Performance may vary based on system hardware & configuration
* Performance may vary based on system hardware & configuration
General Feature
Application
Client PCs, Game Consoles
Rated Capacity
1,000GB (1GB=1 Billion byte by IDEMA)
* Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor
M.2 (2280)
Interface
PCIe Gen 4.0 x4, NVMe 2.0
Dimension (WxHxD)
80 x 24.3 x 8.2 mm (with heatsink)
Weight
Max 28.0g Weight
Storage Memory
Samsung V-NAND 3-bit MLC
Controller
Samsung In-house Controller
Cache Memory
Samsung 1GB Low Power DDR4 SDRAM
Special Feature
TRIM Support
Supported
S.M.A.R.T Support
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
Encryption Support
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support
Not supported
Device Sleep Mode Support
Yes
Performance
Sequential Read
Up to 7,450 MB/s *
Sequential Write
Up to 6,900 MB/s *
Random Read (4KB, QD32)
Up to 1,200,000 IOPS *
Random Write (4KB, QD32)
Up to 1,550,000 IOPS *
Random Read (4KB, QD1)
Up to 22,000 IOPS *
Random Write (4KB, QD1)
Up to 80,000 IOPS *
* Performance may vary based on system hardware & configuration
Environment
Average Power Consumption (system level)
Average: 5.4 W* Maximum: 7.8 W (Burst mode)*
Power Consumption (Idle)
Max. 50 mW *
Allowable Voltage
3.3 V ± 5 % Allowable voltage
Reliability (MTBF)
1.5 Million Hours Reliability (MTBF)
Operating Temperature
0 - 70°C Operating Temperature
Shock
1,500 G & 0.5 ms (Half sine)
* Actual power consumption may vary depending on system hardware & configuration
Software
Management SW
Magician Software for SSD management
Warranty
5-Year Limited Warranty or 600 TBW Limited Warranty
