Overview
Dimensions
212.9 x 113 x 32.5 mm (8.4 x 4.4 x 1.3")
WiFi Standard
WiFi 7
Spatial Streams
4
Mounting Locations
Desktop, wall
Power Method
DC jack (54V DC/1.1A)
Power Supply
54V DC/1.1A (Adapter included)
Performance
MIMO
6 GHz: 2 x 2
5 GHz: 2 x 2
5 GHz: 2 x 2
Max. Data Rate
6 GHz: 5.8 Gbps (BW320)
5 GHz: 4.3 Gbps (BW240)
5 GHz: 4.3 Gbps (BW240)
Antenna Gain
6 GHz: 8 dBi
5 GHz: 8 dBi
5 GHz: 8 dBi
Max. TX Power
6 GHz: 23 dBm
5 GHz: 26 dBm
5 GHz: 26 dBm
Max. Conducted TX Power
26 dBm (Combined)
Supported Data Rates
802.11be (WiFi 7)
6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0-MCS13 NSS1/2, EHT 20/40/80/160/320)
5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0-MCS13 NSS1/2, EHT 20/40/80/160/240)
802.11ax (WiFi 6)
7.3 Mbps to 2.4 Gbps (MCS0-MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0-MCS9 NSS1/2, VHT 20/40/80/160)
802.11n
6.5 Mbps to 300 Mbps (MCS0-MCS15, HT 20/40)
802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps
6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0-MCS13 NSS1/2, EHT 20/40/80/160/320)
5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0-MCS13 NSS1/2, EHT 20/40/80/160/240)
802.11ax (WiFi 6)
7.3 Mbps to 2.4 Gbps (MCS0-MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0-MCS9 NSS1/2, VHT 20/40/80/160)
802.11n
6.5 Mbps to 300 Mbps (MCS0-MCS15, HT 20/40)
802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps
Wireless Security
WPA3 SAE (Always On)
Hardware
Max. Power Consumption
25 W (Excluding PoE output)
Supported Voltage Range
42.5-57 V DC
Networking Interface
(1) 10 GbE RJ45 port
(7) 2.5 GbE RJ45 ports
(7) 2.5 GbE RJ45 ports
PoE Interface
(8) PoE+ ports
Max. PoE Wattage per Port
30 W
Total PoE Availability
60 W AC adapter input: 35 W
210 W AC adapter input: 185 W*
210 W AC adapter input: 185 W*
*210W adapter (sold separately).
Antennas
(1) Internal
Management
Ethernet, WiFi
Channel Bandwidth
20/40/80/160/240/320 MHz
Weight
Device: 548 g (1.21 lb)
With mount: 563 g (1.24 lb)
With mount: 563 g (1.24 lb)
Enclosure Material
Polycarbonate
Mount Material
Polycarbonate
LCM Display
0.96" status display
Button
(1) Factory-reset
NDAA Compliant
Yes
Certifications
CE, FCC, IC
Operating Frequency
Worldwide:
5150-5875 MHz
5945-7125 MHz
5150-5875 MHz
5945-7125 MHz
Ambient Operating Temperature
-30 to 40° C (-22 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
Software
Application Requirements
UniFi Network: Version 10.0.156 or later
