Ubiquiti UniFi 5G Max, A High-Performance 5G (3.4 GBps) Modem, Unifi Deployment. Adopt Through UniFi PoE Port, Delivers Automatic Setup, dual SIM/eSIM

UBIQUITI
Price:
$959.00

Description

  • Overview
    Dimensions
    180 x 109 x 33.8 mm (7.1 x 4.3 x 1.3")
    Networking Interface
    (1) 2.5 GbE RJ45 port
    5G NR and LTE radio
    SIM
    (1) Nano SIM
    (1) Nano-SIM or eSIM

    Nano-SIM 2 cannot be used when an eSIM is active.

    PoE Interface
    (1) PoE input
    Mounting
    Desktop stand, wall, window mount (Included)
    Tamper Resistance
    IK04
    Mechanical
    Weight
    Device: 410 g (14.5 oz)
    Stand: 215 g (7.6 oz)
    Wall mount: 7.6 g (0.3 oz)
    Window mount: 20 g (0.7 oz)
    Enclosure Material
    Polycarbonate, aluminium alloy
    Mount Material
    Polycarbonate, silicone rubber
    Hardware
    Management
    Ethernet
    Category
    5G NR
    5G NR Frequency Bands
    n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n71, n75, n76, n77, n78, n79
    5G NR Max. TX Power
    HPUE power class 2: 26 dBm
    4G LTE Frequency Bands
    B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71
    4G LTE Max. TX Power
    HPUE power class 2: 25 dBm
    3G UMTS Frequency Bands
    B1, B2, B4, B5, B8, B19
    Peak Data Speed - 5G NSA
    Downlink 3.4 Gbps
    Uplink 560 Mbps

    * Speed depends on network coverage and performance at the device location

    Peak Data Speed - 5G SA
    Downlink 1.8 Gbps
    Uplink 650 Mbps
    Peak Data Speed - 4G LTE
    Downlink 1.6 Gbps
    Uplink 210 Mbps
    Antennas
    Type: (4) Embedded cellular antennas
    Max. Power Consumption
    14.5 W
    Power Method
    PoE
    Display
    1.3" touchscreen
    Buttons
    (1) Factory reset
    Ambient Operating Temperature
    0 to 40 °C (32 to 104 °F)
    Ambient Operating Humidity
    5 to 95% noncondensing
    Certifications
    CE, PTCRB, GCF
    Software
    Application Requirements
    UniFi Network: Version 10.0.162 and later

    An alternative internet connection (e.g., standard ISP or WAN) is required to update UniFi consoles and Cloud Gateways before U5G-Max adoption.
