Ubiquiti UniFi Express 7, Mesh-scalable, Super-compact 10G Cloud Gateway, Integrated WiFi 7 With 6 GHz support, 140 m² Coverage
Ubiquiti UniFi Express 7, Mesh-scalable, Super-compact 10G Cloud Gateway, Integrated WiFi 7 With 6 GHz support, 140 m² Coverage
Roll over image to zoom in Click on image to zoom
Ubiquiti UniFi Express 7, Mesh-scalable, Super-compact 10G Cloud Gateway, Integrated WiFi 7 With 6 GHz support, 140 m² CoverageUbiquiti UniFi Express 7, Mesh-scalable, Super-compact 10G Cloud Gateway, Integrated WiFi 7 With 6 GHz support, 140 m² Coverage

Ubiquiti UniFi Express 7, Mesh-scalable, Super-compact 10G Cloud Gateway, Integrated WiFi 7 With 6 GHz support, 140 m² Coverage

UBIQUITI
Price:
$499.00

Description

  • Technical Specs
    Overview
    Dimensions
    117 x 117 x 42.5 mm (4.61 x 4.61 x 1.67'')
    Form Factor
    Compact desktop
    Coverage Area
    160 m² (1,750 ft²)
    UniFi Application Suite
    Network
    Yes
    Managed Devices
    30
    Simultaneous Users Connected
    300
    Connectivity
    Default WAN Ports
    (1) 10 GbE RJ45
    LAN Ports
    (1) 2.5 GbE RJ45
    IDS/IPS Throughput
    2.3 Gbps
    Security
    Stateful Firewall
    Yes
    Application-Aware Layer 7 Firewall
    Yes
    DPI & Traffic Identification
    Yes
    Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
    Yes
    Content Filtering
    Yes
    Intrusion Prevention (IPS/IDS)
    Yes
    Ad Blocking
    Yes
    IDS/IPS Signatures
    20,000+ with CyberSecure
    VLAN/Subnet-based Traffic Segmentation
    Yes
    VPN & SD-WAN
    License-Free SD-WAN
    Yes
    Site-to-Site VPN
    Site Magic
    Yes
    IPsec
    Yes
    OpenVPN
    Yes
    VPN Server
    Identity Endpoint One-Click VPN
    Yes
    Teleport Zero-Configuration VPN
    Yes
    WireGuard
    Yes
    OpenVPN
    Yes
    L2TP
    Yes
    VPN Client
    OpenVPN
    Yes
    WireGuard
    Yes
    Networking
    Dynamic Routing
    OSPF
    Advanced QoS
    Yes
    Multicast DNS (mDNS)
    Yes
    Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
    Yes
    Integrated RADIUS Server
    Yes
    RADIUS over TLS (RadSec)
    Yes
    Additional Internet Failover with UniFi LTE Backup
    Yes
    Internet Quality and Outage Reporting
    Yes
    Policy-based WAN and VPN Routing
    Yes
    Customisable DHCP Server
    Yes
    IPv6 ISP Support
    Yes
    IGMP Proxy
    Yes
    Integrated WiFi
    WiFi Standard
    802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
    Throughput - 6 GHz
    5.7 Gbps
    Throughput - 5 GHz
    4.3 Gbps
    Throughput - 2.4 GHz
    688 Mbps
    MIMO - 6 GHz
    2 x 2 (DL/UL MU-MIMO)
    MIMO - 5 GHz
    2 x 2 (DL/UL MU-MIMO)
    MIMO - 2.4 GHz
    2 x 2 (DL/UL MU-MIMO)
    Antenna Gain - 6 GHz
    6 dBi
    Antenna Gain - 5 GHz
    7 dBi
    Antenna Gain - 2.4 GHz
    4 dBi
    Wireless Security
    WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
    Max. BSSIDs
    4 per Radio (Gateway Mode), 4 per Radio (AP Mode)
    Supported Data Rates
    802.11a
    6, 9, 12, 18, 24, 36, 48, 54 Mbps
    802.11b
    1, 2, 5.5, 11 Mbps
    802.11g
    6, 9, 12, 18, 24, 36, 48, 54 Mbps
    802.11n
    6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
    802.11ac (WiFi 5)
    6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
    802.11ax (WiFi 6/6E)
    7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
    802.11be (WiFi 7)
    7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
    Hardware
    Max. Power Consumption
    22W
    Power Method
    USB Type-C (5V DC/5A)
    Power Supply
    USB Type-C (5V DC/5A) (Adapter included)
    Max. TX Power - 6 GHz
    24 dBm
    Max. TX Power - 5 GHz
    26 dBm
    Max. TX Power - 2.4 GHz
    23 dBm
    Supported Voltage Range
    100-240V AC
    Processor
    Quad-core ARM® Cortex®-A53 at 1.5 GHz
    System Memory
    3 GB
    Weight
    422 g (14.9 oz)
    Enclosure Material
    Polycarbonate
    LCM Display
    0.96" status display
    Management
    Ethernet
    Bluetooth
    LEDs
    Ethernet
    ESD/EMP Protection
    Air: ± 8kV, Contact: ± 4kV
    Ambient Operating Temperature
    -10 to 40° C (14 to 104° F)
    Ambient Operating Humidity
    5 to 95% noncondensing
    Certifications
    CE, FCC, IC
    Button
    (1) Factory-reset
    Software
    VLAN
    802.1Q
    Guest Traffic Isolation
    Yes
    Application Requirements
    UniFi Network Version 9.0.108 and later
