Description
- (1) 1.3" LCM colour touchscreen with AR switch management
- (8) 10G SFP+ ports
- 160 Gbps switching capacity
- Fanless, near-silent cooling
Managed with the UniFi Network application: Version 5.14.12 and later
Fully Managed, Layer 2 Switch
The Switch Aggregation is a fully managed, Layer 2 switch with (8) 10G SFP+ ports designed to enhance your network's switching capacity and performance by creating high-bandwidth aggregation links. This rack-mountable switch also offers 160 Gbps switching capacity and features a 1.3" LCM colour touchscreen that concisely displays key system and connection insights. Additionally, with its 4.7" depth, it's easy to mount this compact, fanless switch in a SOHO rack cabinet. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Works with the UniFi Network Application
- Centrally manage multiple networks from an intuitive interface
- Enjoy real-time device insights and deep configuration options
- Upgrade device firmware remotely
- Manage network users and guests with ease
- Personalize the design, architecture, and privacy of guest hotspots
- Set up devices quickly and manage them on the go with a powerful mobile app
442.4 x 120 x 43.7 mm
Without Mount: 2.65 kg
With Mount: 2.74 kg
SGCC Steel
80 Gbps
160 Gbps
119.04 Mpps
30W
Universal AC Input: 100-240VAC, 50/60 Hz
AC/DC, Internal, 36W
Ethernet In-Band
SMB Layer 2 Gigabit Ethernet Switch
UACC-OM-MM-10G: 8
UACC-OM-SM-10G: 8
UACC-CM-RJ45-10G: 4
Air: ± 16kV, Contact: ± 12kV
-5 to 40° C
10 - 90% Non Condensing
CE, FCC, IC
Bootup in Progress
Firmware Upgrading
Factory Defaults, Awaiting Adoption
Device is Adopted
White: 10G, 1G
